Optical System
-
Beam Angel: 1.5°- 35°linear fast zooming
Focus: High percision optical lens,electronic linear control
Prism: 12+36 facet circular prism in both directions at variable speeds -
Control and Programming
-
Channel mode: 16/18/24
Linear Dimmer: Mechanical dimmer 0-100%
Strobe: 1-18/second,double lens strobe with adjustable speed
Control mode: Standard DMX 512, 3 pin,5 pin connector -
Static Gobos
-
17 interchangeable gobos +white, and bidirectionally rotatable and gobo shaking at variable speeds
-
Rotating Gobos
-
12 rotating gobos+White bi-directional rotatable and gobo shaking at variable speeds
-
Framing Shutters System
-
Fan Cooling
-
Animation Wheel
-
1 color wheel with 14 fixed color+open,half-tone effect, linear color conversion, bidirectionally rotatable at variable speeds and rainbow effect.
-
Electrical Specification
-
ingInput voltage range: 100-240 V, 50/60 Hz
Power consumption: 1000 W at 230 V / 50 Hz -
Mechanical Specification
-
Net Weight: 19KG
Gross Weight: 21KG(Carton)
