Source
-
Light source type: 300W Discharge short arc lamp with integrated reflector
light source life expectancy:3000 hrs
Color Temperature:8000K
-
Optical System
-
Zoom range 2°
-
Control and Programming
-
Protocols: USITT DMX-512
WDMX,RDM
DMX protocol modes: 2
Control channels: 13, 16
-
Static Gobos
-
Image diameter:6.5mm
Thickness: 0.5 mm
Material: Aluminiu
Static Gobo wheel: 17 gobos -
Electrical Specification
-
Power supply: Electronic auto-ranging
Input voltage range: 100--240 V, 50/60 Hz
Power consumption: 500 W at 230 V / 50 Hz
Power in connector: powerCON TRUE1
DMX and RDM data in / out: 3-pin or 5-pin XLR -
Rigging
-
Mounting points: 2 pairs of 1 -turn locking points
2x Omega brackets with 1-turn quick locks
Universal operating position
